Schneider Electric MS4D-7033-150
SKU: CS653992MPN: MS4D-7033-150UPC/EAN: 711426700251
Act (MS4D-7033-150): Elec, Prop, 0-10 VDC, SR, 20-30 VDC/24 VAC/VDC, Plen, 30 in-lb, Rotary, N2, SmartX
$341.29
UnitAvailable on backorder
Product Details
Actuator: (MS4D-7033-150):
- Actuator Type: Electric
- Control Signal: Proportional
- Control Signal Range: 0 to 10 VDC
- Loss of Power Type: Spring Return
- Power Input Voltage: 20 to 30 VDC, 24 VAC/VDC
- Leads and Connections: 3 ft Plenum
- Torque: 30 in-lb
- Mechanical Movement: Rotary
- Protection Rating: NEMA 2
- Product Line: Schneider Electric
- Product Range: SmartX Actuator
- Product Series: MS4D-7xxx
- Actuator Use: Ball Valves, Dampers
Attributes
| Us Rated Supply Voltage | 20…30 V DC 24 V AC/DC |
| Actuator | rotary |
| Actuator Rotation | 93 ° |
| Ambient Air Temperature For Operation | -30-60 °C |
| Ambient Air Temperature For Storage | -40-71 °C |
| Analogue Input Range | 0…10 V DC |
| Control Type | automatic reset |
| Current Consumption | 120 mA |
| Electrical Insulation Class | class II |
| Hold In Power Consumption In W | 1.4-1.4 W |
| Ip Degree Of Protection | IP11 |
| Material | polymer: housing |
| Motor Type | brush DC motor |
| Power Consumption In Va | 6.1 VA AC |
| Power Consumption In W | 3.4 W |
| Product Destination | ball valves dampers |
| Product Or Component Type | actuator |
| Relative Humidity | 15-95 % non-condensing |
| Switch Function | No |
| Targeted Region | North America. |
| Taxoclass Id | PTC_D54013_XXX |
| Tightening Torque | 30 lb.in# #3.4 N.m |
Specifications
| SKU | CS653992 |
|---|---|
| MPN | MS4D-7033-150 |
| UPC/EAN | 711426700251 |
