ACI QRP-II

Name: ACI QRP-II
Brand: ACI
SKU: CS6291093
Availability: OutOfStock

SKU: CS6291093MPN: QRP-IIAlternate Part #: 151169

REMOTE PANEL WITH RELAYS

Product Details

REMOTE PANEL WITH RELAYS

Product Configuration

Series	Controllers
Configuration	None
Sensing Element	None
Configuration Modification	Remote LCD with Relays and Override

Product Family Specifications

Input	Digital: 4 Parallel RS-485 ports allow up to 32 QEL gas sensors, and up to 99 relays Analog: 8 channels of 4-20 mA inputs with one common Binary: 2 dry-contact switch inputs
Buzzer	90 db @ 12” (30 cm), 2700 Hz; 3 Buzzer tones
Keypad	6X tactile \& audible keypad
Output	Optional 8 analog channels of 4-20 mA signals with one common
Display	Four-line Backlit LCD
# of Relays	Three SPDT Form C, Dry Contact \| 5.0A resistive 240 VAC, 30 VDC \| 3.7A inductive 240 VAC, 30 VDC
Programming	On-board keypad or M-View software (software and USB programming cable included)
Time Delays	Actuation / De-Actuation: 0 to 60 minutes
Horn \& Strobe	Two dedicated dry contact terminals with dedicated 24VDC power terminal, 750mA Max
Product Weight	5.00 lbs (2268 g)
Supply Voltage	18 to 30VDC, 24VDC nominal \| 15 to 24VAC 50/60HZ, 24VAC nominal \| Half-wave or full wave rectified
Agency Approvals	Standard UL 2017, 2^nd Edition 2008
Communication Wire	Belden 9841 or equal
Product Dimensions	(H) 10.00” (254 mm) x (W) 8.00” (203 mm) x (D) 2.00” (51 mm)
Operating Environment	Indoor Use only
Relay Life Expectancy	Mechanical: Minimum 5,000,000
Status LED Indication	Ten (10) LEDs: Three (3) Relay status, Hush, Fault, and Power \|TX/RX Status for Sensor Network TX/RX Status for Modbus/BACnet Network
Communication Protocol	Modbus RTU (Slave) or BACnet IP(Optional)
Connections \| Wire Size	Terminal Blocks \| Depluggable, Power Wiring: 16 to 26 AWG (0.2 to 1.00 nm²) Twisted Pair
Operating Humidity Range	0% to 95% RH Continuous non-condensing
Storage Temperature Range	32ºF to 68ºF (0ºC to 20ºC) 0 to 99% RH Non-Condensing
Enclosure Material \| Color	Steel, epoxy painted black, NEMA 1
Operating Temperature Range	-4ºF to 122ºF (-20ºC to 50ºC)
Terminal Block Torque Rating	0.37 ft-lbs (0.5n-3m) Nominal
Supply Current / Power Consumption	750mA Max
