ACI A/TTM1K-SP-1

SKU: CS6288731MPN: A/TTM1K-SP-1Alternate Part #: 142561

Transmitter w/ 1,000 Ohm RTD (NIST Cert), Wall Plate, Stainless Steel, 1-5VDC Output

ACI A/1.8K-AP, A/1.8K-SP, A/100-2W-SP, A/100-3W-SP, A/100KS-AP, A/100KS-SP, A/10K-E1-AP, A/10K-E1-SP, A/10KS-AP, A/10KS-SP, A/1K-2W-SP, A/1K-2W-SP-NIST, A/1K-3W-SP, A/1K-NI-AP, A/1K-NI-SP
Contact us for pricing and availability

Product Details

Transmitter w/ 1,000 Ohm RTD (NIST Cert), Wall Plate, Stainless Steel, 1-5VDC Output

Product Configuration

Sensor TTM1K (XMTR, 1K Ω, NIST)
Transmitter Output 1-5VDC

Product Family Specifications

Stability +/- 0.03% after 1000 Hours @ 300ºC (572vF)
Sensor Type Platinum RTD
Number Wires Two
Sensor Curve PTC (Positive Temperature Coecient)
Thermal Drift Temp. Spans \< 100ºF (38ºC): +/- 0.04%/ºF | Temp. Spans > 100ºF (38ºC): +/- 0.02% Thermal Drift is referenced to 71ºF nominal calibration temperature
Output Signals Current: 4-20 mA (2-Wire Loop Powered) Voltage: 1-5 VDC or 2-10 VDC (3-Wires)
Plate Material 430 Stainless Steel (Brushed Stainless Steel Finish)
Product Weight 0.19 lbs. (86.2 g)
Sensor Accuracy +/- 0.06% Class A | (Tolerance Formula: +/- ºC \= (0.15ºC + (0.002 * |t|)) where |t| is the absolute value of temperature above or below 0ºC in ºC)
Agency Approvals RoHS2, WEEE
Lead Wire Colors A/TT100/TTM100-SP: Brown/Brown A/TT1K/TTM1K-SP: Black/Black
Conductor Material Silver Plated Copper
NIST Certification 3 Point NIST: 20%, 50% \& 80% of span 5 Point NIST: 20%, 35%, 50%, 65%, 80% of span
Product Dimensions 4.50” (114.3 mm) x 2.78” (70.6 mm) x 1.00” (25.4 mm)
Number Sensing Points One
Connections | Wire Size Screw Terminal Blocks (Polarity Sensitive) | 16 AWG (1.31 mm2) to 26 AWG (0.129 mm2)
Maximum Load Resistance (Terminal Voltage - 8.5 V) | 0.020 A
Operating Humidity Range 5 to 90% RH, non-condensing
Min/Max Temperature Spans Minimum Temp. Span: 50ºF (28ºC) Maximum Temp. Span: 200ºF (93ºC)
Storage Temperature Range -40 to 160ºF (-40 to 71ºC)
Operating Temperature Range 35ºF to 160ºF (1.5 to 71ºC)
Lead Length | Conductor Size 14” (35.6 cm) | 22 AWG (0.65 mm)
Sensor Output @ 0ºC (32ºF) A/TT100/TTM100-SP: 100 Ohms nominal A/TT1K/TTM1K-SP: 1000 Ohms nominal
Terminal Block Torque Rating 0.37 ft-lb (0.5 Nm ) nominal
Warm Up Time | Warm Up Drift 10 Minutes | +/- 0.1%
Calibrated Accuracy | Linearity Temp. Spans \< 500ºF (260ºC): +/- 0.2% Transmitter’s calibrated at 71ºF (22ºC) nominal
Response Time (63% Step Change) 20 Seconds nominal
Lead Wire Insulation | Wire Rating Etched Teflon (PTFE) Colored Leads | Mil Spec 16878/4 Type E
Din Standard | Temperature Coeffcient DIN EN 60751 (IEC 751) | 3850 ppm / ºC
Foam Pad Material | Flammability Rating Neoprene/EPDM/SBR Polymer | UL94-HBF; FMVSS-302; MIL-R-6130C
Transmitter Supply Voltage | Supply Current +8.5 to 32 VDC (Reverse Polarity Protected) | 25 mA minimum 250 Ohm Load: +13.5 to 32 VDC | 500 Ohm Load: +18.5 to 32 VDC
