ACI A/TT1K-O-SUN-4

Name: ACI A/TT1K-O-SUN-4
Brand: ACI
SKU: CS6287213
Availability: OutOfStock

SKU: CS6287213MPN: A/TT1K-O-SUN-4Alternate Part #: 132324

Transmitter w/ 1,000 Ohm RTD, Outside Air, Sun Shield, 4-20mA Output

ACI A/1.8K-O-SUN, A/1.8K-O-SUN-NIST, A/100-2W-O-SUN, A/100-2W-O-SUN-NIST, A/100-3W-O-SUN, A/10KS-O-SUN, A/1K-2W-O-SUN, A/1K-NI-O-SUN, A/20K-O-SUN, A/3K-O-SUN, A/AN-BC-O-SUN, A/AN-O-SUN, A/BALCO-O-SUN, A/CP-O-SUN-NIST, A/CSI-O-SUN

Product Details

Transmitter w/ 1,000 Ohm RTD, Outside Air, Sun Shield, 4-20mA Output

Product Configuration

Sensor	TT1K (XMTR, 1K Ω)

Product Family Specifications

Stability	+/-0.03% after 1000 Hours @ 572°F (300°C)
Probe Material	304 Stainless Steel
Product Weight	4.16 lbs(1.89 kg)
Agency Approvals	RoHS2, WEEE
TT Output Signals	Current Output: 4-20 mA (2-Wire Loop Powered) \| Voltage Output: 1-5 VDC or 2-10 VDC (3-Wires)
Operating RH Range	0 to 90% RH, non-condensing
Product Dimensions	14.95” (379.7 mm) x 7.50” (190.50 mm)
TT Temperature Drift	Temperature Spans \< 100°F (38°C): +/- 0.04%/°F \| Temperature Spans > 100°F (38°C): +/- 0.02%/°F
TT Maximum Load Resistance	(Terminal Voltage – 8.5 V) \| 0.020 A
Sensor Tolerance \| Accuracy	+/- 0.06% Class A \| Tolerance Formula: +/- °C \= (0.15°C + (0.002 * \|t\|) where \|t\| is the absolute value of Temperature above or below 0°C in °C)
TT Warm Up Time \| Warm Up Drift	10 Minutes \| +/- 0.1%
Platinum RTD Output @ 32°F (0°C)	A/TT100 Series: 100 Ohms Nominal \| A/TT1K Series: 1000 Ohms Nominal
TT Calibrated Accuracy \| Linearity	Temperature Spans \< 500°F (260°C): +/- 0.2% \| Temperature Spans > 500°F (260°C): +/- 0.5%
TT Supply Voltage \| Supply Current	+8.5 to 32 VDC (Reverse Polarity Protected) \| 25 mA minimum 250 Ohm Load: +13.5 to 32 VDC \| 500 Ohm Load: +18.5 to 32 VDC
TTM100/TTM1K NIST Certification Points	3 Point NIST: 20%, 50% \& 80% of span \| 5 Point NIST: 20%, 35%, 50%, 65%, 80% of span
Transmitter Operating Temperature Range	-40 to 185°F (-40 to 85°C)
Platinum RTD Response Time (63% Step Change)	8 Seconds nominal
Platinum RTD (PTC) \| Number Wires (Wire Colors)	Two \| A/TT100 Series: Brown/Brown \| A/TT1K Series: Black/Black
Enclosure Specifications (Material, Flammability, Temperature, NEMA/IP Rating)	“-4X” Enclosure: Polystyrene Plastic; UL94-V2; -40 to 158°F (-40 to 70°C); NEMA 4X (IP 66)
