ACI A/1.8K-S-PB

Name: ACI A/1.8K-S-PB
Brand: ACI
SKU: CS6286567
Availability: OutOfStock

SKU: CS6286567MPN: A/1.8K-S-PBAlternate Part #: 124136

1,800 Ohm Thermistor, Strap On, Plastic Enclosure

ACI A/1.8K-S-PB, A/100-2W-S-PB, A/100-3W-S-PB, A/100-3W-S10-PB, A/100KS-S-PB, A/10K-E1-S-PB, A/10KS-S-PB, A/1K-2W-S-PB, A/1K-3W-S-PB, A/1K-NI-S-PB, A/3K-S-PB, A/50K-S-PB, A/AN-BC-S-PB, A/AN-S-PB, A/BALCO-S-PB

Product Details

1,800 Ohm Thermistor, Strap On, Plastic Enclosure

Product Configuration

Length	1.25” to 4” Pipe Size
Sensor	1.8K (1,800 Ω)
Enclosure	Plastic

Product Family Specifications

Sensor Type	Thermistor
Number Wires	Two (Non-Polarity Sensitive)
Sensor Curve	Non-Linear, NTC (Negative Temperature Coefficient)
Product Weight	A/XX-S-GD: 0.80 lbs. (0.37kg) \| A/XX-S-PB: 0.40 lbs. (0.18kg) \| A/XX-S-4X: 0.55 lbs. (0.25kg)
Agency Approvals	CE, RoHS2, WEEE
Conductor Material	Silver Plated Copper
Pipe Sizes Accepted	A/X-S-XX: 1 ¼” (32mm) to 4” (100mm); A/X-S10-XX: 2” (50mm) to 10” (250mm)
Number Sensing Points	One
Operating Humidity Range	10 to 95% RH, non-condensing
Storage Temperature Range	-40 to 80ºC (-40 to 176ºF)
Power Dissipation Constant	3 mW/ºC except A/1.8K Series: 1 mW/ºC \| A/10K-E1 Series: 2 mW/ºC
Accuracy 0-70ºC (32-158ºF)	+/-0.2ºC (+/-0.36ºF) except A/10K-E1 Series: +/-0.3ºC (+/-0.54ºF); A/1.8K Series: +/- 0.5ºC @ 25ºC (77ºF) and (+/-1.0ºC) (+/-1.8ºF)
Lead Length \| Conductor Size	A/XX-S-XX: 14” (35.6cm) \| A/XX-S10-XX: 22 AWG (0.65mm)
Response Time (63% Step Change)	30 Seconds nominal
Lead Wire Insulation \| Wire Rating	Etched Teflon (PTFE) Colored Leads \| MIL-W-16878/4 (Type E)
Foam Pad Material \| Flammability Rating	Neoprene/EPDM/SBR Polymer \| UL94-HF1; MIL-R-6130C; FMVSS-302
Nominal Thermistor Resistive Output @ 77°F (25°C) (Lead Wire Colors)	A/1.8K: 1.8KΩ nominal \| (Red/Yellow) A/3K: 3KΩ nominal \| (White/Brown) A/AN (Type III): 10KΩ nominal \| (White/White) A/AN-BC: 5.238KΩ nominal \| (White/Yellow) A/CP (Type II): 10KΩ nominal \| (White/Green) A/CSI: 10KΩ nominal \| (Green/Yellow) A/10KS: 10KΩ nominal \| (White/Blue) A/10K-E1: 10KΩ nominal \| (Gray/Orange) A/20K: 20KΩ nominal \| (Brown/Blue) A/50K: 50KΩ nominal \| (Brown/Yellow) A/100KS: 100KΩ nominal \| (Black/Yellow)
Enclosure Specifications (Material, Flammability, Temperature, NEMA/IP Rating)	A/XX-S-GD: Galvanized Steel, -40 to 93ºC (-40 to 200ºF), NEMA 1 (IP 10) A/XX-S-PB: ABS Plastic, -30 to 85ºC (-22 to 185ºF), UL94-HB, Plenum Rated A/XX-S-4X: Polystyrene Plastic, -40 to 70ºC (-40 to 158ºF), UL94-V2, NEMA 4X (IP 66)
