ACI A/1K-NI-A-24'-4X

Name: ACI A/1K-NI-A-24'-4X
Brand: ACI
SKU: CS6285959
Availability: OutOfStock

SKU: CS6285959MPN: A/1K-NI-A-24'-4XAlternate Part #: 120481

1,000 Ohm Nickel RTD, Copper Averaging, 24’, NEMA 4X Enclosure

Product Details

1,000 Ohm Nickel RTD, Copper Averaging, 24’, NEMA 4X Enclosure

NIST	None
Length	24’
Enclosure	NEMA 4X

Stability	+/- 0.05% after 1000 Hours @ 150ºC (302ºF)
Sensor Type	Nickel RTD
Number Wires	Two (Non-Polarity Sensitive)
Sensor Curve	PTC (Positive Temperature Coefficient)
Sensor Accuracy	8’ \& 12’ Lengths: +/- 0.31ºC (+/- 0.56ºF) @ 21.1ºC (70ºF) \| +/- 0.71ºC (+/- 1.28ºF) @ 54.4ºC (130ºF) 24’ Lengths: +/- 0.41ºC (+/- 0.74ºF) @ 21.1ºC (70ºF) \| +/- 0.87ºC (+/- 1.56ºF) @ 54.4ºC (130ºF)
Agency Approvals	RoHS2, WEEE
Lead Wire Colors	Red/Red
Conductor Material	Silver Plated Copper
Number Sensing Points	8’ \& 12’ Lengths: Four 24’ Length: Nine
Operating Humidity Range	10 to 95% RH, non-condensing
Storage Temperature Range	-40 to 85ºC (-40 to 185ºF)
Operating Temperature Range	-40 to 250ºF (-40 to 212ºC)
Lead Length \| Conductor Size	12” (30.5cm) \| 22 AWG (0.65mm)
Response Time (63% Step Change)	8 Seconds nominal
Sensor Output @ 21.1ºC (70ºF)	1000 Ohms nominal
Lead Wire Insulation \| Wire Rating	Etched Teon (PTFE) Colored Leads \| MIL-W-16878/4 (Type E)
Din Standard \| Temperature Coeffcient	Din 43760 \| 6370 ppm/ºC
Fitting Material \| Flammability Rating	Polyamide 66 (High Performance Nylon) \| UL94-HB
Foam Pad Material \| Flammability Rating	Neoprene/EPDM/SBR Polymer \| UL94-HBF; FMVSS-302; MIL-R-6130C
Self-Heating \| Maximum Operating Current	0.3ºC/mW (Still Air) \| 5 mA
Sensing Element Material \| Element Diameter	Copper \| 0.210” (5.34mm) nominal
