Schneider Electric MA41-7073

SKU: CS609304MPN: MA41-7073UPC/EAN: 711426483130

SmartX, Damper Actuator, 2-position, spring return, 24 Vac/Vdc, 3 ft appliance cable, 60 lb-in, NEMA 1 or 2

Schneider Electric MA41-7070, MA41-7073, MF41-7073, MS41-7073
$430.54
Unit
2 Units Available at Factory - Ships Same/Next Business Day
remove
add

Product Details

Actuator: (MA41-7073):

  • Actuator Type: Electric
  • Control Signal: 2-Position (On/Off)
  • Loss of Power Type: Spring Return
  • Power Input Voltage: 22 to 30 VDC, 24 VAC/VDC
  • Leads and Connections: 3 ft Appliance
  • Torque: 60 in-lb
  • Mechanical Movement: Rotary
  • Protection Rating: NEMA 1, NEMA 2
  • Product Line: Schneider Electric
  • Product Range: SmartX Actuator
  • Product Series: Mx4x-7xxx
  • Actuator Use: Dampers, Globe Valves

Product Alert: Linkage required for Globe Valve Assembly use. NEMA 2 with conduit connector in the down position.

Attributes

Us Rated Supply Voltage 22…30 V DC 24 V AC/DC
Actuator rotary
Actuator Rotation 95 °
Ambient Air Temperature For Operation -30-60 °C
Ambient Air Temperature For Storage -40-71 °C
Control Type automatic reset
Electrical Insulation Class class II
Ip Degree Of Protection IP10 IP11
Material die cast aluminium: housing
Motor Type brush DC motor
Nema Degree Of Protection NEMA 1# #NEMA 2
Power Consumption In Va 4.8 VA AC
Product Destination dampers globe valve
Product Or Component Type actuator
Relative Humidity 5-95 % non-condensing
Switch Function No
Targeted Region North America.# #Australia.
Taxoclass Id PTC_D54013_XXX
Tightening Torque 60 lb.in# #7 N.m

Specifications

SKUCS609304
MPNMA41-7073
UPC/EAN711426483130
