Omega ITHX-SD-2

Name: Omega ITHX-SD-2
Brand: Omega
SKU: CS5797082
Price: 881.26 USD
Availability: OutOfStock

SKU: CS5797082MPN: ITHX-SD-2

Chart Recorder for Temperature \& Humidity

Omega ITHX-SD-2, ITHX-SD-2-2D, ITHX-SD-2-5D, ITHX-SD-2D, ITHX-SD-5, ITHX-SD-5-2D, ITHX-SD-5-5D, ITHX-SD-5D, ITHX-SD-WD

$881.26

Unit

Available on backorder

Quantity

remove

add

Documents

Product Details

Charting Web Server Application
Alarms by Email or Text Message
Record Years of Data on Popular SD Cards
Temperature

Attributes

Width	2.93 in
Height	1.44 in
Length	3.56 in
Weight	0.86 lb
Software	Compatible with Windows operating systems, Firmware upgrade from Ethernet OPC Server, iConnect: Configuration software for the Ethernet interface, iLog: Macro for automatic data logging in MS Exce
Approvals	CE, FCC-B
Materials	316 Stainless Steel, Stainless Steel
Series ID	ITHX-SD-Series
Hysteresis	± 1% RH
Input Type	External
Probe Type	Industrial Probe
Form factor	Wall Bracket Mount
Samples,Max	85k Samples, Interval 1 sec
Battery life	Back-up Battery Life: up to 60 hr, with reading interval of 1 min
Cable Length	3 ft
Display Note	16 digits, 6mm (0.23”)
Probe Length	2 in
Relay Output	1.5 A @ 30 Vdc
Configuration	Internal Web UI
Logging Modes	Fixed interval
Non-Linearity	± 3%
RH Resolution	0.1%, 12 bit
Repeatability	± 0.1%
Response Time	Temperature: 5 to 30 sec, RH: 8 sec
Certifications	NIST Traceable Calibration
Data Interface	Ethernet
Probe Diameter	0.63 in
Supply Current	0.5 A
Supply Voltage	9 to 12 Vdc
Accuracy Detail	Temperature Sensor Accuracy: Industrial Probe: ± 0.5°C for 5° to 45°C, Up to ± 1.5°C for -40° to 5°C and 45° to 124°C, Relative Humidity Accuracy: ± 2.75% for 10 to 90%; ± 3% for 5 to 10% and 90 to 95%, ± 4% for 0 to 5% and 95 to 100%
Measurement Type	Relative Humidity, Temperature
Number of Relays	2
Country of Origin	Mexico
Supply Power Note	AC Power Adapter (included) , Nominal Output: 9 Vdc @ 0.5 A , Input: 100 to 240 Vac, 50/60Hz, Back-up Battery: 9 Vdc, alkaline
Supply Power Type	DC/Battery
Data Interface Note	Ethernet : (RJ45) Fixed or auto negotiating 10/100BASE-T, AUTO MDI/MDIX Supported Protocols:TCP, UDP, SNMP, SMTP, NTP, ARP, ICMP, DHCP, DNS, HTTP, and Telnet
RH Measurement Range	0 to 100% RH
Temperature Accuracy	± 0.5 °C
Battery Size and Type	Alkaline 9V
Electrical Connection	Sub-D Male Miniature Connector
Cable Temperature, Max	125 °C
Cable Temperature, Min	-40 °C
Number of Measurements	2
Temperature Resolution	0.1 °C, 14 bit
Storage Temperature, Max	85 °C
Storage Temperature, Min	-40 °C
Temperature Repeatability	± 0.1 °C
Operating Temperature Note	iServer Unit: 0 to 60°C Battery: -18 to 55°C ac Power Adapter: 0 to 40°C Industrial Cable: -40 to 125°C
Operating Temperature, Max	60 °C
Operating Temperature, Min	0 °C
Relative Humidity Accuracy	± 2.75% RH
Temperature Measurement, Max	124 °C
Temperature Measurement, Min	-40 °C
Battery Operating Temperature	-18 to 55 °C
AC Adaptor Operating Temperature	0 to 40 °C
