Trane SEN02142

Name: Trane SEN02142
Brand: Trane
SKU: CS5558614
Availability: OutOfStock

SKU: CS5558614MPN: SEN02142

SENSOR; SPLIT CORE ADJUSTABLE MINI CURRENT SWITCH

Product Details

SENSOR; SPLIT CORE ADJUSTABLE MINI CURRENT SWITCH

Diameter (In)	0.53
Enclosure Type	NEMA 1
Type	Split Core Adjustable Mini Current Switch
Color	Yellow
Standards	UL
Temperature Rating	-22 to 140 Deg. F
Current Rating	0.7 - 150 A
New Long Description-500	SENSOR, SPLIT CORE ADJUSTABLE MINI CURRENT SWITCH, 0.53IN DIAMETER, 2.35IN WIDTH, 2.65IN LENGTH, 0.95IN HEIGHT, 600VAC, 0.7 TO 150A CURRENT, 50/60HZ, -30DEG F MIN TEMPERATURE, 60DEG C MAX TEMPERATURE, NEMA 1 ENCLOSURE, MEETS UL, FOR CRITICAL MOTORS, LIGHTING CIRCUITS, ANCILLARY EQUIPMENT, FANS, PUMPS, AND COMPRESSORS
New Short Description- 150	SENSOR,SPLIT CORE ADJUSTABLE MINI CURRENT SWITCH,0.53IN DIA,2.35IN WD,2.65IN LG,0.95IN HT,600VAC,0.7 TO 150A CURRENT,50/60HZ,-30DEG F MIN TEMP,UL
Frequency Rating	50/60Hz
Switching Voltage	Not Available
Voltage Rating (Vac)	600
Warranty	5 Years
Sensing Range	0.70 to 150A
Operating Humidity Range [Rh]	0 to 95%
Response Time (Sec)	<45 MSec

SKU	CS5558614
MPN	SEN02142
