Schneider Electric VS-7253-593-4-09

SKU: CS5489983MPN: VS-7253-593-4-09

SmartX, Globe Valve Assembly, 1-¼ in, 2-Way, Stem Up Open, 20 cv, MS51-7203 Spring Return Proportional Actuator

Schneider Electric VS-7253-593-4-09, VS-7253-593-4-10, VS-7253-593-4-11, VS-7273-593-4-09, VS-7273-593-4-10, VS-7273-593-4-11
$1,010.45
Unit
Available on backorder
remove
add

Product Details

Valve Assembly:

  • Body Size: 1-¼ in
  • Configuration: 2-Way
  • Type: Globe
  • Body Pattern: Straightway
  • Connection: NPT
  • Stem Flow Action: Stem up A open
  • Material Trim: Stainless Steel
  • Flow Coefficient: 20 cv
  • Close-Off Pressure: 150 PSI
  • Actuator Type: Electric
  • Control Signal: Proportional
  • Control Signal Range: 2 to 10 VDC, 4 to 20 mAdc
  • Loss of Power Type: Spring Return
  • Loss of Power Position: Normally open
  • Power Input Voltage: 24 VAC/VDC, 22 to 30 VDC
  • Leads and Connections: 3 ft Appliance
  • Force: 220 lbf
  • Mechanical Movement: Linear
  • Protection Rating: NEMA 2

Assembly Components:

  • Valve Body: VB-7253-0-4-09
  • Valve Range: Venta
  • Valve Linkage: None, tool-less connection
  • Actuator: MS51-7203
  • Actuator Range: SmartX Actuator

Specifications

SKUCS5489983
MPNVS-7253-593-4-09
