All ProductsTurck

Turck REM-101SA0S-9F32B-H1151

SKU: CS5390664MPN: REM-101SA0S-9F32B-H1151Alternate Part #: 100023546
Turck REM-101S10S-9F32B-H1151, REM-101S6S-9F32B-H1151, REM-101S8S-9F32B-H1151, REM-101SA0S-9F32B-H1151, REM-190S10S-IOL32B-H1141, REM-190SA0S-IOL32B-H1141, RES-184S10S-9F14B-H1151, RES-184S6S-9F14B-H1151, RES-184S8S-9F14B-H1151, RES-184SA0S-9F14B-H1151, RES-192S10S-IOL14B-H1141, RES-192S6S-IOL14B-H1141, RES-192S8S-IOL14B-H1141, RES-192SA0S-IOL14B-H1141
$833.15
Unit
Available on backorder
remove
add

Product Details

Absolute Rotary Encoder - Multiturn

Industrial Line

  • Synchro flange, Ø 36 mm
  • Solid shaft, Ø 6.35 mm × 12.5 mm
  • Magnetic measuring principle
  • Shaft material: stainless steel
  • Protection class IP67 on housing and shaft side
  • ‐40…+80 °C
  • Max. 4000 rpm (continuous operation 2000 rpm)
  • 10-30 VDC
  • SAE J1939
  • M12 connection, 5-pin
  • Singleturn resolution 14 bit scalable, default 14 bit
  • Multiturn resolution scalable up to 29 bit over total resolution, default 18 bit
  • Total resolution 32 bit scalable, default: 32 bit

Attributes

Ambient Temperature -40…+80 °C
Communication Protocol SAE J1939
Customs Tariff Number 90318080000.0000
Ecl Ss Code V5 1 4 27270501 -/- Encoder, absolute
Electrical Connection Connector, M12 × 1
Encoder Line Industrial-Line
Flange Diameter Ø  36 mm
Flange Type Synchro flange
Housing Material Die-cast zinc
Operating Voltage 10…30 VDC
Output Type Absolute multiturn
Protection Class IP67
Protection Class Shaft IP67
Shaft Diameter D Mm 6.35 mm
Shaft Type Solid shaft
Technology Magnetic

Specifications

SKUCS5390664
MPNREM-101SA0S-9F32B-H1151
Alternate Part #100023546
