Danfoss 077F1397

Name: Danfoss 077F1397
Brand: Danfoss
SKU: CS5083449
Availability: OutOfStock

SKU: CS5083449MPN: 077F1397

Electronic thermostat control, ETC 1H3

Product Details

Function: Standard thermostat, Supply voltage [V] AC: 230, Packing format: Industrial pack, Quantity per packing format: 120

Approval	CE
Aux Contacts No Pc	2 pc
Aux Contacts Rating	5A (MK4,MK6)
China Rohs Compliance	Out of scope
Coating	Coated PCB
Cold Cut Out C	0 °C
Cold Cut Out F	32 °F
Cold Difference C	1 °C
Cold Difference F	33.8 °F
Defrost Sensor Type	077F8750 - 8768
Defrost Temp C	5 °C
Defrost Temp F	41 °F
Defrost Type	Method 2
Eu Rohs Compliance	Out of scope
Frequency Hz	50/60 Hz
Function	Standard thermostat
Main Relay Rating	16(16) A
Min Off Time S	300 s
Min On Time S	300 s
Number Of Terminals Pcs	6 pc
Other Rohs Documentation	EAEU RoHS
Packing Format	Industrial pack
Product Accessories	Electron. control accessories
Product Group	Temperature controllers
Product Name Description	Electronic thermostat control
Quantity Per Packing Format	120 pc
Reach Candidate List Substances	No
Serviceable	No
Spade Terminal Size Mm	6.3 x 0.8 mm tab
Spindle	With stop
Supply Voltage V Ac	230 V
Temp Sensor Type	077F8751 - 8769
Temp Setting	Knob
Type	ETC 1H3
Uk Rohs Compliance	Out of scope
Volume	0.197 Liter
Warm Cut Out C	10 °C
Warm Cut Out F	50 °F
Warm Difference C	1 °C
Warm Difference F	33.8 °F
