All ProductsDanfoss

Danfoss 121L1376

SKU: CS5082712MPN: 121L1376

Scroll compressor, HRH054U4LP6

Contact us for pricing and availability

Product Details

Refrigerants: R410A, Segment usage: Air conditioning, Compressor power supply [V]: 380-415/3/50 460/3/60, Packing format: Single pack

Attributes

Approval CCC
Brand Technique Scroll compressor
Capacity Control Fixed speed
China Rohs Compliance Out of scope
Colour Blue
Compressor Power Supply V 380-415/3/50 460/3/60
Configuration Code Single
Connection Type Brazed
Diameter Mm 184 mm
Discharge Connection Pipe Size In ½ in
Discharge Connection Size In ½ in
Drawing Number 0XR6002B-2
Economizer No
Eu Rohs Compliance Yes with exemptions
Eu Rohs Exemption Clause 6(a), 6(a)-I, 7(a), 7©-I, 8(b), 9(b)
Family HRH
Fitting Standard ODF
Frequency Hz 50/60
Gauge Port Hp None
Gauge Port Lp None
Gaz Equalization None
Glass Mounting None
High Value Of Nominal Voltage At 50Hz V 415 V
High Value Of Nominal Voltage At 60Hz V 460 V
High Value Of Voltage Range At 50Hz V 457 V
High Value Of Voltage Range At 60Hz V 506 V
In Scope Of Weee And Contain Batteries No
Ip Protection Class IP22
Low Value Of Nominal Voltage At 50Hz V 380 V
Low Value Of Nominal Voltage At 60Hz V 460 V
Low Value Of Voltage Range At 50Hz V 342 V
Low Value Of Voltage Range At 60Hz V 414 V
Lra 70 A
Max Pressure Ps High Side 46.1 bar
Max Pressure Ps Low Side 31.1 bar
Mcc 15 A
Model Number HRH054U4LP6
Motor Protection Internal overload protector
Network Power Supply V Ph Hz 380-415/3/50 460/3/60
Number Of Starts Per Hour Max 12
Oil Charge L 1.57 L
Oil Drain None
Oil Equalization None
Oil Reference 320HV
Oil Type PVE
Packing Format Single pack
Packing Quantity 1
Phase 3
Power Connections Spade
Product Group Hermetic compressors
Product Name Description Scroll compressor HRH
Reach Candidate List Substances Lead (CAS no. 7439-92-1)
Refrigerant Charge Kg Max 5.44 kg
Refrigerants R410A
Rla 9.6 A
Rotational Speed At 50Hz Rpm 2900 rpm
Rotational Speed At 60Hz Rpm 3500 rpm
Scip Dossier No 22cfab5a-a26e-446d-9517-3ee5f4753699
Segment Usage Air conditioning
Shipped Mounting Mounting kit with grommets and sleeves
Shipped Oil Initial oil charge
Suction Connection Material -
Suction Connection Pipe Size In ⅞ in
Suction Connection Size In ⅞ in
Swept Volume Cm3 52.11 cm³
Technology Scroll
Type HRH054
Uk Rohs Compliance Out of scope
Viscosity Cp 68 cP
Volume 0.05 Cubic.mtr
Winding Resistance 1 2 Ohm 2.32
Winding Resistance 1 3 Ohm 2.33
Winding Resistance 2 3 Ohm 2.36

Specifications

SKUCS5082712
MPN121L1376
