All ProductsDanfoss

Danfoss 121L0581

SKU: CS5082636MPN: 121L0581

Scroll compressor, HCM094T4LC6

Contact us for pricing and availability

Product Details

Refrigerants: R22, Segment usage: Air conditioning, Compressor power supply [V]: 380-415/3/50 460/3/60, Packing format: Single pack

Attributes

Approval CE
Brand Technique Scroll compressor
Capacity Control Fixed speed
China Rohs Compliance Out of scope
Colour Blue
Compressor Power Supply V 380-415/3/50 460/3/60
Configuration Code Single
Connection Type Brazed
Diameter Mm 184 mm
Discharge Connection Pipe Size In ⅞ in
Discharge Connection Size In ⅞ in
Drawing Number 0SR4103B-3
Economizer No
Eu Rohs Compliance Yes with exemptions
Eu Rohs Exemption Clause 6(a), 6(a)-I, 7(a), 7©-I, 8(b), 9(b)
Family HCM
Fitting Standard ODF
Frequency Hz 50/60
Gauge Port Hp None
Gauge Port Lp None
Gaz Equalization None
Glass Mounting None
High Value Of Nominal Voltage At 50Hz V 415 V
High Value Of Nominal Voltage At 60Hz V 460 V
High Value Of Voltage Range At 50Hz V 457 V
High Value Of Voltage Range At 60Hz V 506 V
In Scope Of Weee And Contain Batteries No
Ip Protection Class IP22
Low Value Of Nominal Voltage At 50Hz V 380 V
Low Value Of Nominal Voltage At 60Hz V 460 V
Low Value Of Voltage Range At 50Hz V 342 V
Low Value Of Voltage Range At 60Hz V 414 V
Lra 95 A
Max Pressure Ps High Side 31.1 bar
Max Pressure Ps Low Side 26.2 bar
Mcc 21 A
Model Number HCM094T4LC6
Motor Protection Internal overload protector
Network Power Supply V Ph Hz 380-415/3/50 460/3/60
Oil Charge L 2.66 L
Oil Equalization None
Oil Reference 160ABM
Oil Type Alkylbenzene
Packing Format Single pack
Packing Quantity 1
Phase 3
Power Connections Screw connectors 10-32 UNF x 9.5
Product Group Hermetic compressors
Product Name Description Scroll compressor HCM
Reach Candidate List Substances Lead (CAS no. 7439-92-1)
Refrigerant Charge Kg Max 7.26 kg
Refrigerants R22
Rla 13.5 A
Rotational Speed At 50Hz Rpm 2900 rpm
Rotational Speed At 60Hz Rpm 3500 rpm
Scip Dossier No 6987e9ab-f9b7-473c-9c29-6cb05443e8ef
Segment Usage Air conditioning
Suction Connection Material -
Suction Connection Pipe Size In 1 ⅛ in
Suction Connection Size In 1 ⅛ in
Swept Volume Cm3 126.02 cm³
Technology Scroll
Torque Earth Nm 2 N-m
Torque Power Nm 3 N-m
Type HCM094
Uk Rohs Compliance Out of scope
Viscosity Cp 32 cP
Volume 0.06 Cubic.mtr
Winding Resistance 1 2 Ohm 1.48
Winding Resistance 1 3 Ohm 1.48
Winding Resistance 2 3 Ohm 1.48

Specifications

SKUCS5082636
MPN121L0581
