Eaton 13157RL17B1
SKU: CS5018902MPN: 13157RL17B1UPC/EAN: 782114523094
Eaton OEM Prism 18mm tubular photoelectric sensor
Contact us for pricing and availability
Product Details
Eaton OEM Prism 18mm tubular photoelectric sensor, OEM Prism Series Tubular Photoelectric Sensor, Right Angle, Sensor distance: 24 In., Iso SS Relay, 80 mA at 132 Vac/110 mA at 132Vdc, 6.6 Ft. (2m) Cable input
Attributes
| Cable Type | Polyvinyl Chloride (PVC) |
| Connection | 6.6 ft (2 m) cable |
| Contact Configuration | Isolated solid state relay |
| Contact Rating | 80 mA at 132 Vac / 110 mA at 132Vdc |
| Enclosure Material | Lens: polycarbonate Body: structural polyurethane foam Cable jacket: PVC |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13 |
| Input Voltage | 10-30 Vdc |
| Led Indicator | Output status: red |
| Maximum Ac Current | 80 mA |
| Maximum Dc Current | 110 mA |
| Operating Mode | Diffuse reflective |
| Operating Temperature Max | 131 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -13 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Current limited for loads less than 32 Vac/dc |
| Sensor Type | Diffuse reflective |
| Switch Type | Photoelectric |
Specifications
| SKU | CS5018902 |
|---|---|
| MPN | 13157RL17B1 |
| UPC/EAN | 782114523094 |
