Eaton 1251E-8543
SKU: CS5018655MPN: 1251E-8543UPC/EAN: 782116112968
Eaton Enhanced 50 photoelectric sensor
Contact us for pricing and availability
Product Details
Eaton Enhanced 50 Series Photoelectric Sensor, Sensor distance: 500 Ft., Iso SS Relay, 300 mA at 240 Vac/Vdc, 4 Pin Dual Key Micro Connector, 12–240 Vdc 24–240 Vac input, Reverse polarity, short circuit and overload, Yes, Thu-Beam
Attributes
| Connection | 4-pin dual key micro connector |
| Contact Configuration | Isolated solid state relay |
| Contact Rating | 300 mA at 240 Vac/Vdc |
| Enclosure Material | Fiberglass reinforced plastic |
| Environmental Rating | IP67, IP69K |
| Input Voltage | 12-240 Vdc, 24-240 Vac |
| Led Indicator | Power on: yellow Marginal gain: red Output status: green |
| Maximum Ac Current | 300 mA |
| Maximum Dc Current | 300 mA |
| Operating Mode | Thru-beam |
| Operating Temperature Max | 131 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -13 FAH |
| Operating Temperature Min Uom | FAH |
| Protection | Reverse polarity and short circuit protected |
| Sensor Type | Through beam |
| Switch Type | Photoelectric |
| Time Delay | Yes |
Specifications
| SKU | CS5018655 |
|---|---|
| MPN | 1251E-8543 |
| UPC/EAN | 782116112968 |
