Eaton 11100AQD03
SKU: CS5018341MPN: 11100AQD03UPC/EAN: 782113843360
Eaton Comet 18mm tubular photoelectric sensor
Contact us for pricing and availability
Product Details
Eaton Comet 18mm tubular photoelectric sensor, Photoelectric, 0.71 diameter, Forward Viewing, Sensor distance: 20 Ft., Lens: Polycarbonate Cable Jacket, 4 Pin Dual Key Micro Connector, 20-264 Vac/15-30 Vdc input, Thru-beam, 8 In. ( .2m )
Attributes
| Cable Type | Polyvinyl Chloride (PVC) |
| Connection | 4-pin dual key micro connector |
| Enclosure Material | Body: structural polyurethane foam Cable jacket: PVC Lens: polycarbonate |
| Environmental Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K |
| Input Voltage | 20-264 Vac, 15-30 Vdc |
| Led Indicator | Power on: red |
| Operating Mode | Thru-beam |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | -4 FAH |
| Operating Temperature Min Uom | FAH |
| Sensor Type | Through beam |
| Switch Type | Photoelectric |
Specifications
| SKU | CS5018341 |
|---|---|
| MPN | 11100AQD03 |
| UPC/EAN | 782113843360 |
