Eaton 10250T853LD2A
SKU: CS5017737MPN: 10250T853LD2AUPC/EAN: 782114541555
Eaton 10250T pushbutton
Discontinued - Contact Us For Pricing & Availability
Product Details
Eaton 30.5 mm Heavy-Duty Push-Pull Unit,Class I Division 2,Standard Actuator,Blue,Plastic Bus,1NO-1NC,Illuminated,120 Vac Lamp voltage,LED, full voltage,24 Vac/Vdc Light Unit,Two-position,Momentary push and pull,40 mm button,10250T Series
Attributes
| Actuator | Standard |
| Actuator Color | Blue |
| Bus Material | Plastic |
| Contact Configuration | 1 NO-1 NC |
| Illumination | Illuminated |
| Lamp Voltage Max | 120 VAC |
| Lamp Voltage Max Uom | VAC |
| Lamp Voltage Min | 120 VAC |
| Lamp Voltage Min Uom | VAC |
| Light Unit Type | LED, full voltage |
| Light Unit Voltage | 120 Vac |
| Number Of Positions | 2 |
| Operating Mode | Pull: momentary Push: momentary |
| Rating | NEMA 3 NEMA 4X NEMA 13 NEMA 4 NEMA 3R NEMA 12 NEC Class I Division 2, Groups B, C and D |
| Series | 10250T |
| Size | 40 mm |
| Type | Class I Division 2 |
Specifications
| SKU | CS5017737 |
|---|---|
| MPN | 10250T853LD2A |
| UPC/EAN | 782114541555 |
