Eaton UAFHTRS223ASHCH
SKU: CS4993602MPN: UAFHTRS223ASHCHUPC/EAN: 786685974576
Eaton meter socket
$190.00
UnitAvailable on backorder
Product Details
Eaton meter socket, 1-pos resi service, 200A, Under, Solid top, #8-350 kcmil, 4-jaw, 1-ph, #8-350 kcmil, Al screw type seal ring, barrel lock w guard provision, Horn bypass, Gnd conn (#14-#2 Cu), Al, Triplex, 3-wire, Ringless, 600 Vac
Attributes
| Accessories | Aluminum screw type sealing ring |
| Amperage Rating | 200A |
| Bypass | Horn |
| Connection | Ground connection |
| Enclosure Material | 063 Aluminum |
| Feed Type | Bottom |
| Hub Type | Solid top |
| Line | #8-350 kcmil |
| Load | #8-350 kcmil |
| Number Of Jaws | Four-jaw |
| Number Of Sockets | 1.0000 |
| Number Of Wires | Three-wire |
| Phase | Single-phase |
| Security | Ringless |
| Special Features | Offset design |
| Type | Single-position residential service |
| Utility Approvals | TX : Southwestern Electric Power Company (SWEPCO) (AEP West) AR : Southwestern Electric Power Company (SWEPCO) (AEP West) TX : AEP Texas (AEP West) OK : Public Service Company of Oklahoma (PSO) (AEP West) LA : Southwestern Electric Power Company (SWEPCO) (AEP West) KY : Kentucky Power (AEP West) |
| Voltage Rating | 600 V |
| Voltage Rating Uom | INH |
Specifications
| SKU | CS4993602 |
|---|---|
| MPN | UAFHTRS223ASHCH |
| UPC/EAN | 786685974576 |
