Eaton E53KBL18T111SD

Name: Eaton E53KBL18T111SD
Brand: Eaton
SKU: CS4872488
Price: 616.40 USD
Availability: OutOfStock

SKU: CS4872488MPN: E53KBL18T111SDUPC/EAN: 782114013052

Eaton E53 tubular capacitive proximity sensor

$616.40

Unit

Available on backorder

Quantity

remove

add

Product Details

Eaton E53 tubular capacitive proximity sensor, Threaded body, 0.31 in range, Straight, 18 mm, Shielded, Output ON, M12, 300 mA Solid State Output, 4 pin, NC PNP open collector, 10-30 Vdc

Attributes

Actuator Function	Shielded
Connection	M12
Contact Configuration	NC PNP open collector
Contact Rating	300 mA Solid State Output
Enclosure Material	POM Mounting nuts Nylon PA66
Environmental Rating	NEMA 1, NEMA 2, NEMA 3, NEMA 3S, NEMA 4, NEMA 12, NEMA 13, IP65
Input Voltage	10-30 Vdc
Led Indicator	Output ON Output
Maximum Dc Current	300 mA
Number Of Pins	4.0000
Operating Temperature Max	158 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	-13 FAH
Operating Temperature Min Uom	FAH
Protection	Short circuit and reverse polarity
Series	E53
Type	Threaded body
