Eaton E50GNG1

Name: Eaton E50GNG1
Brand: Eaton
SKU: CS4871881
Availability: OutOfStock

SKU: CS4871881MPN: E50GNG1UPC/EAN: 782113308913

Eaton E50 NEMA heavy duty plug-in limit switch

Eaton E50AH1RFY1, E50AL16P20, E50AL1P5, E50ALH1, E50ALH16P, E50ALL1, E50ALL16P, E50ALM1, E50ALM16P, E50ALM16P20, E50ALR1, E50ALR16P, E50ALR16P12, E50ALR16P20, E50ALR16PC

Product Details

Eaton E50 NEMA heavy duty plug-in limit switch,Screw Terminals,5A at 120 Vac,1NO-1NC,Die Cast Zinc,NEMA 1,3,3S,4,4X,6,6P,13,IP67,Neon ( 120 Vac ),5A,14° to 201°F (-10° to 94°C),Side Rotary,Gravity Return

Attributes

Accuracy	Refer to installation publication P15836
Connection	Screw terminal
Contact Configuration	1 NO-1 NC
Contact Rating	5A at 120 Vac
Enclosure Material	Die cast zinc
Environmental Rating	NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
Led Indicator	Neon (120 Vac)
Maximum Ac Current	5 A
Operating Temperature Max	201 FAH
Operating Temperature Max Uom	FAH
Operating Temperature Min	14 FAH
Operating Temperature Min Uom	FAH
Switch Type	Gravity return Side rotary
