Eaton E47BCC15P4
SKU: CS4871511MPN: E47BCC15P4UPC/EAN: 786685293318
Eaton E47 limit switch
Contact us for pricing and availability
Product Details
E47BCC Series Compact Pre-Wired Limit Switch, Side Rotary, Die Cast Aluminum enclosure, 5A max AC, 5A max DC, 5A at 240 Vac/5A at 14 Vdc, 4 Pin M12 Connector
Attributes
| Connection | 4-pin M12 connector |
| Contact Configuration | SPDT |
| Contact Rating | 5A at 240 Vac/5A at 14 Vdc |
| Enclosure Material | Die cast aluminum |
| Environmental Rating | NEMA 4, NEMA 6, NEMA 13, IP67 |
| Maximum Ac Current | 5 A |
| Maximum Dc Current | 5 A |
| Operating Temperature Max | 158 FAH |
| Operating Temperature Max Uom | FAH |
| Operating Temperature Min | 14 FAH |
| Operating Temperature Min Uom | FAH |
| Switch Type | Side rotary |
| Type | E47 |
Specifications
| SKU | CS4871511 |
|---|---|
| MPN | E47BCC15P4 |
| UPC/EAN | 786685293318 |
