Schneider Electric VB-7224-0-4-02
SKU: CS483493MPN: VB-7224-0-4-02
Venta, Globe Valve, ½ in, 2-way, Straightway, Sweat, Stemp Up Closed, Brass, 1.3 cv
Contact us for pricing and availability
Product Details
Valve Body (VB-7224-0-4-02):
- Body Size: ½ in
- Configuration: 2-Way
- Type: Globe
- Body Pattern: Straightway
- Connection: Sweat
- Stem Flow Action: Stem up A closed
- Material Trim: Brass
- Flow Coefficient: 1.3 cv
- Control Media: Glycol 25 to 60%, Steam, Water
- Product Line: Schneider Electric
- Product Range: Venta
- Product Series: VB-7200
Attributes
| Body Material | bronze |
| Operating Fluid Temperature | -7-138 °C |
| Product Or Component Type | valve |
| Saturated Steam Temperature | -7-138 °C |
| Satured Steam Inlet Pressure | 35 psi |
| Seat Leakage | Port A: Class IV (0.01 %) Port A: Class V |
| Seat Material | Port A: bronze |
| Seating Seal Material | PTFE (polytetrafluoroethylene) |
| Targeted Region | North America. |
| Taxoclass Id | PTC_D54015_XXX |
Specifications
| SKU | CS483493 |
|---|---|
| MPN | VB-7224-0-4-02 |
