Veris U013-0013

BACnet Router

The BACnet router provides access to all Veris BACnet MS/TP products over a network using BACnet IP protocol.

Specifications:

• Downstream 2-wire BACnet MS/TP RS-485* Downstream Baud rate of 9600 to 78,600* Upstream 10/100 Mb Ethernet, Fixed IP* Supply voltage 24VDC +/- 10%, 2W or 24VAC +/-10% 4VA 47 to 63 Hz* Operating Temperature 0 deg. C to 60 deg. C (32 deg. F to 140 deg. F)
