Square D SSP02EMA12D

Name: Square D SSP02EMA12D
Brand: Square D
SKU: CS4813639
Availability: OutOfStock

SKU: CS4813639MPN: SSP02EMA12DUPC/EAN: 785901972587

Surge protection device, Surgelogic, 120kA, 208Y/120 VAC, 3 phase, 4 wire, NEMA 1, disconnect switch

Product Details

Surge Protection Device

Surge Current: 120 kA* System Voltage: 208Y/120V AC* Phase: 3 Phases* Wire Configuration: 4-Wire* Connections - Terminals: Lugs AWG 10-AWG 3/0 copper Torque to: 4 N.m* Maximum Continuous Operating Voltage: 150V* Number of Poles: 3* Line Rated Current: 150A* Local Signaling: Status LED, green \= normal operation per phase, Status LED, red \= fault per phase* Provided Equipment: Surge counter, Switch-disconnector, Alarm enable/disable switch, Dry contacts* Device Mounting: Surface* Dimensions: 19.49 H x 9.88 W x 5.31in. D* Degree of Protection: NEMA 1

In Rated Current	150 A
In Rated Current 1	150 A
Uc Maximum Continuous Operating Voltage	150 V
Ambient Air Temperature For Operation	65-65 °C
Ambient Air Temperature For Operation 1	65-65 °C
Device Short Name	EMA
Nema Degree Of Protection	NEMA 1
Network Number Of Phases 1	3 phases
Nominal Discharge Current	20 kA
Number Of Poles	3.0
Product Or Component Type	surge protection device
Range Of Product	Surgelogic
Short Circuit Protection	200 kA
Wiring Configuration	4-wire
