Square D LV432490
SKU: CS4811810MPN: LV432490
Terminal extensions, ComPacT NSX 400/630, spreaders 45mm to 52.5mm pitch, set of 3 parts
Contact us for pricing and availability
Product Details
These accessories are spreaders for 3 poles Compact NSX 400/630 and EasyPact CVS 400/630. They are screwed to the circuit-breaker terminals to increase the pitch between poles from 45mm to 52.5mm. The rated current is up to 630 A. These spreaders are supplied with flexible interphase barriers for insulation reinforcement. They are sold by set of 3 parts.
Attributes
| Accessory Separate Part Category | connection accessory |
| Connection Pitch | 52.5 mm |
| Mounting Position | straight |
| Poles Description | 3P |
| Product Or Component Type | spreader |
| Quantity Per Set | 3 |
Specifications
| SKU | CS4811810 |
|---|---|
| MPN | LV432490 |
