Square D LV429630

Name: Square D LV429630
Brand: Square D
SKU: CS4811806
Availability: OutOfStock

SKU: CS4811806MPN: LV429630

Circuit breaker, ComPact NSX100F, 36kA/415VAC, TMD trip unit 100A, 3 poles 3d

Product Details

Circuit breaker Compact NSX100F - TMD - 100 A - 3 poles 3d

Rated insulation voltage[Ui] : 800 V AC 50/60 Hz.
Rated current [In] : 100 A (40 deg C).
Rated operational voltage [Ue] : 690 V AC 50/60 Hz.
trip unit rating : 100 A (40 degC)
Trip unit technology :Thermal-magnetic.
Protection type : Overload protection (thermal) L, Short-circuit protection (magnetic) I
Short-time pick-up adjustment range [Isd] : 800 A.
IP degree of protection : IP40 conforming to IEC 60529.

Isd Short Time Pick Up Adjustment Range	800 A
Ambient Air Temperature For Operation	-25-70 °C
Ambient Air Temperature For Operation 1	-25-70 °C
Ambient Air Temperature For Storage	-50-85 °C
Control Type	toggle
Device Application	distribution
Device Short Name	NSX100F
Downside Connection	front
Earth Leakage Protection	without
Electrical Shock Protection Class	class II
Long Time Delay Adjustment Type	fixed
Long Time Pick Up Adjustment Range	0.7…1 x In
Long Time Pick Up Adjustment Type Ir	adjustable
Mechanical Durability	50000 cycles
Mounting Mode	fixed
Mounting Support	backplate
Network Frequency	50/60 Hz
Network Type	AC
Overvoltage Category	class II
Poles Description	3P
Product Certifications	CCC# #EAC# #Marine
Product Name	ComPact NSX
Product Or Component Type	circuit breaker
Protected Poles Description	3t
Range	ComPact
Range Of Product	ComPact NSX100…250
Short Time Delay Adjustment Type	fixed
Short Time Pick Up Adjustment Type Isd	fixed
Standards	EN/IEC 60947
Trip Unit Name	TM-D
Trip Unit Protection Functions	LI
Trip Unit Technology	thermal-magnetic
Upside Connection	front
Utilisation Category	category A

SKU	CS4811806
MPN	LV429630
