Square D LC1F185BD

Name: Square D LC1F185BD
Brand: Square D
SKU: CS4811662
Availability: OutOfStock

SKU: CS4811662MPN: LC1F185BD

TeSys F contactor - 3P (3 NO) - AC-3 - \<\= 440 V 185 A - coil 24 V DC

Square D LC1F150BD, LC1F150F7, LC1F185BD, LC1F185U7, LC1F330F7, LC1F330P7

Product Details

TeSys D Contactor- Number of Poles: 3-Poles- Pole Contact Composition: 3 NO- Rated Operational Current: 185A- Control Circuit Voltage: 24V DC- Non-Reversing

Attributes

Ambient Air Temperature For Operation	-5-55 °C
Ambient Air Temperature For Operation 1	-5-55 °C
Ambient Air Temperature For Storage	-60-80 °C
Coil Type	standard
Compatibility Code	LC1F
Contactor Application	motor control# #resistive load
Device Short Name	LC1F
Mechanical Durability	10 Mcycles
Motor Starter Type	direct on-line contactor
Motor Starter Type 1	direct on-line contactor
Mounting Support	plate
Overvoltage Category	III
Pole Contact Composition	3 NO
Poles Description	3P
Product Certifications	RMRoS# #LROS (Lloyds register of shipping)# #ABS# #CB# #DNV# #BV# #RINA# #UL# #CSA# #UKCA
Product Name	TeSys F
Product Or Component Type	contactor
Range	TeSys
Standards	EN 60947-1# #IEC 60947-4-1# #IEC 60947-1# #JIS C8201-4-1# #EN 60947-4-1
Utilisation Category	AC-4# #AC-1# #AC-3
