Square D 8536SCH3V02S

Name: Square D 8536SCH3V02S
Brand: Square D
SKU: CS4809773
Availability: OutOfStock

SKU: CS4809773MPN: 8536SCH3V02SUPC/EAN: 785901810278

NEMA Motor Starter, Type S, nonreversing, Size 1, 27A, 10 HP at 460 VAC, 5 kA SCCR, 3 phase, 3 pole, melting alloy, 120 VAC coil, NEMA 3R

Product Details

Type S Full Voltage Starter

NEMA Size: Size 1* Degree of Protection: NEMA 3R Rainproof* Control Circuit Voltage: 110V AC 50 Hz, 120V AC 60 Hz* Line Rated Current: 27A* Poles Description: 3-Poles* Number of Phases: 3-Phase* Control Circuit: Separate Control Circuit* Motor Starter Type: Non-Reversing* Electrical Connection: Screw Clamp Terminals

In Rated Current	27 A
In Rated Current 1	27 A
Auxiliary Contact Composition	without
Control Circuit	separate control circuit
Electrical Connection	screw clamp terminals
Motor Starter Type	non reversing
Motor Starter Type 1	non reversing
Nema Size	1
Network Number Of Phases	3 phases
Poles Description	3P
Product Certifications	UL listed# #CSA# #NEMA
Product Or Component Type	motor starter
Range Of Product	S
