Carrier RG2PV50T6N

Bradford White - RG2PV50T6N Power Vent TTW 50 gal. Natural Gas Water Heater

Bradford White - Residential Power Vent Gas Water Heater

ENERGY STAR® Qualified—Some models qualify for the September 1, 2010 minimum ENERGY STAR® EF requirement, as well as most utility rebate programs.

Bradford White ICON System™—Intelligent gas control with spark to pilot ignition system eliminates the constant burning pilot. This results in savings of pilot gas during standby periods (120 V.A.C.).

• Enhanced Performance—Proprietary algorithms provide enhanced First Hour Delivery ratings and tighter temperature differentials.
• Advanced Temperature Control System—Microprocessor constantly monitors and controls burner operation to maintain consistent and accurate water temperature levels.
• Intelligent Diagnostics—An exclusive green LED light prompts the installer during start-up and provides ten different diagnostic codes to assist in troubleshooting.

Features:

• Power Vented Water Heater - designed for installations where atmospheric units cannot be used. Exhaust gases are vented under positive pressure directly out of the building through the roof or the wall
• Powerful Blower Motor - our significantly quiet design has greater resistance to outside winds and the power to vent in many difficult venting situations
• 10’ Power Cord included (120 VAC)
• Horizontal and Vertical Venting - PVC, ABS or CPVC (maximum equivalent vent length on reverse side)
• Advanced ScreenLok® Technology Flame Arrestor Design - Flame arrestor is designed to prevent ignition of flammable vapor outside of the water heater (excluding RG1PV55H6N \& RG2PV75H6N)
• Flammable Vapor Sensor - Electronic sensor prevents burner operation if flammable vapors are detected. The sensor will also prevent operation if there is ongoing flammable vapor burn inside the combustion chamber (excluding RG1PV55H6N \& RG2PV75H6N)
• Maintenance-Free - no regular cleaning of air inlet openings or flame arrestor is required under normal conditions (excluding RG1PV55H6N \& RG2PV75H6N)
• Sight Window - offers a view into the combustion chamber to observe the operation of the pilot and burner
• Factory-Installed Hydrojet® Total Performance System - cold water inlet sediment reducing device helps prevent sediment build-up in tank. This increases first hour delivery, while minimizing temperature build-up at top of tank
• Vitraglas® Lining - Bradford White tanks are lined with an exclusively engineered enamel formula that provides superior tank protection from the highly corrosive effects of hot water. This formula (Vitraglas®) is fused to the steel surface by firing at a temperature of over 1600°F (871ºC)
• Non-CFC Foam Insulation - covers the sides and top, reducing the amount of heat loss. This results in less energy consumption, improved operation efficiencies, and jacket rigidity
• Water Connections - ¾” NPT factory-installed true dielectric fittings
• ¾” NPT Side Connections (RG2PV50H6N, RG1PV55H6N, and RG2PV75H6N only)
• Factory-Installed Heat Traps - design incorporates a flexible disk that reduces heat loss in piping and eliminates the potential for noise generation
• Protective Magnesium Rod (RG1PV55H6N has 2)
• T\&P Relief Valve - installed
• Thermostatic Mixing Valve (ASSE Approved) - included (RG1PV55H6N only)
• Low Restriction Brass Drain Valve - durable tamper-proof design
