Carrier 50PCH048ZCC5ECC1

Carrier® Aquazone™ - 4 Ton Compact Water Source Heat Pumps Horizontal Right Return (208/230-3-60)

50PCH048ZCC5ECC1

50PCH \= Horizontal Configuration Aquazone™ Compact Water Source Heat Pump

048 \= 4 Ton

Z \= Right/Return Left/Discharge PSC/Blower Motor

C \= Standard C Microprocessor Control

C \= Standard Non-Coated Copper Air Coil

5 \= 208/230-3-60

A \= Current Revision

C \= None

C \= Standard Range (50 to 100 F)

1 \= None

Single-package horizontally and vertically mounted water source heat pumps (WSHPs) with solid-state controls.

• Unique double isolation compressor mounting via vibration isolating rubber grommets for quiet operation
• Copeland scroll compressors (rotary 007-015, reciprocating 018-042, scroll 048-070)
• Suitable for geothermal (with extended range option) and boiler/tower use with an operating temperature range of 25 to 110 F
• Hot gas reheat (HGR) available for dehumidification capability
• Backward compatibility for replacing older units from various manufacturers
• Field convertible discharge air arrangement for horizontal units
• Permanent split capacitor (PSC) three-speed fan motor
• Internally trapped condensate drain line (vertical units only)
• Flexible and reliable multiple protocol WSHP Open controller can use BACnet, Modbus, N2, and LonWorks protocols for integrating energy efficiency and precise unit control
• Mute package for quiet operation
• Optional tin-plated copper tubing and polymer coated aluminum fin evaporator coil available
• Non-ozone depleting Puron® refrigerant (R-410A)
