All ProductsTurck

Turck BL20-E-2CNT-2PWM

SKU: CS4210124MPN: BL20-E-2CNT-2PWMAlternate Part #: 6827341UPC/EAN: 4047101252859

6827341 - SYSTEMBUS

Turck BL20-E-16DI-24VDC-N, BL20-E-16DI-24VDC-P, BL20-E-16DO-24VDC-0.5A-N, BL20-E-16DO-24VDC-0.5A-P, BL20-E-16GNDL, BL20-E-16UL, BL20-E-2CNT-2PWM, BL20-E-4AO-U/I, BL20-E-4AO-U/I/ET, BL20-E-8AI-U/I-4PT/NI, BL20-E-8AI-U/I-4PT/NI/ET
$682.83
Unit
Available on backorder
remove
add

Product Details

BL20 Economy Module

2 × Counter/Encoder Channels, 2x PWM Outputs

  • Fieldbus-independent
  • Electronics and connection technology in one housing
  • Connectivity: Push-in terminals
  • Protection class IP20
  • LEDs indicate status and diagnostic
  • Electronics galvanically isolated from the field level via optocouplers
  • 2 x counter/encoder channels 200 kHz
  • 2 PWM outputs 20kHz / 0.5A
  • 2 digital outputs 20kHz / 0.5A
  • Counting mode: Continuous, single or periodic count
  • Measuring principle: Frequency, rotational speed or period duration measurement

Attributes

Ambient Temperature 0…+55 °C
Approvals cULus
Connection Technology Signal Cage clamp terminal
Customs Tariff Number 85389091890.0000
Device Type I/O Module
Ecl Ss Code V5 1 4 27250307 -/- Technology module (periphery)
Protection Class IP20
Signal Type Counter, Digital input, Digital output, PWM

Specifications

SKUCS4210124
MPNBL20-E-2CNT-2PWM
Alternate Part #6827341
UPC/EAN4047101252859
