Turck BI12-GT30-AD4X-0.3-RS4.23T/S1589
SKU: CS4209761MPN: BI12-GT30-AD4X-0.3-RS4.23T/S1589Alternate Part #: 4417085
4417085 - FERRITE, BARREL, DC, PIGTAIL M
$229.14
UnitAvailable on backorder
Product Details
Inductive Sensor
With Weldguard® coating
- Threaded barrel, M30 x 1.5
- Brass, PTFE-coated
- DC 2-wire, 10…65 VDC
- NO contact
- Cable with male end
Attributes
| Ambient Temperature | -25…+70 °C |
| Construction Size | M30 x 1.5 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable with connector, M12 × 1 |
| Housing Material | Metal, CuZn, PTFE-coated |
| Mounting | Flush |
| Operating Voltage | 10…65 VDC |
| Output Function | NO contact, 2-wire |
| Protection Class | IP67 |
| Rated Switching Distance | 12 mm |
| Special Feature | weldguard® |
| Switching Frequency | 0.50 kHz |
Specifications
| SKU | CS4209761 |
|---|---|
| MPN | BI12-GT30-AD4X-0.3-RS4.23T/S1589 |
| Alternate Part # | 4417085 |
