Turck BI2U-EG08-RN6X-V1131
SKU: CS4209475MPN: BI2U-EG08-RN6X-V1131Alternate Part #: 1637152
1637152 - UPROX, BARREL, DC, CON. M8
Contact us for pricing and availability
Product Details
Inductive Sensor
With Extended Switching Distance
- Threaded barrel, M8 x 1
- Stainless steel, 1.4427 SO
- Factor 1 for all metals
- Protection class IP68
- Resistant to magnetic fields
- Large switching distance
- High switching frequency
- Recessed mountable
- DC 3-wire, 10…30 VDC
- NC contact, NPN output
- M8 x 1 male connector
Attributes
| Ambient Temperature | -30…+85 °C |
| Construction Size | M8 x 1 |
| Customs Tariff Number | 85365019900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, M8 × 1 |
| Housing Material | Stainless steel, 1.4427 SO |
| Mounting | Flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NC contact, NPN |
| Protection Class | IP68 |
| Rated Switching Distance | 2 mm |
| Special Feature | uprox+, Factor 1, Resistant to magnetic fields |
| Switching Frequency | 1.0 kHz |
Specifications
| SKU | CS4209475 |
|---|---|
| MPN | BI2U-EG08-RN6X-V1131 |
| Alternate Part # | 1637152 |
