Turck BI3U-M12E-VN4X-H1141
SKU: CS4209343MPN: BI3U-M12E-VN4X-H1141Alternate Part #: 1580354UPC/EAN: 4047101124408
1580354 - UPROX, BARREL, DC, CON. M12
$155.94
UnitAvailable on backorder
Product Details
Inductive Sensor
- M12 × 1 threaded barrel
- Long version
- Chrome-plated brass
- Factor 1 for all metals
- Protection class IP68
- Resistant to magnetic fields
- Extended temperature range
- High switching frequency
- DC 4-wire, 10…65 VDC
- Changeover contact, NPN output
- M12 x 1 male connector
Attributes
| Ambient Temperature | -30…+85 °C |
| Construction Size | M12 x 1 |
| Customs Tariff Number | 85365080900.0000 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Connector, M12 × 1 |
| Housing Material | Metal, CuZn, Chrome-plated |
| Mounting | Flush |
| Operating Voltage | 10…65 VDC |
| Output Function | Complementary contact, NPN |
| Protection Class | IP68 |
| Rated Switching Distance | 3 mm |
| Special Feature | uprox+, Factor 1, Resistant to magnetic fields |
| Switching Frequency | 3.0 kHz |
Specifications
| SKU | CS4209343 |
|---|---|
| MPN | BI3U-M12E-VN4X-H1141 |
| Alternate Part # | 1580354 |
| UPC/EAN | 4047101124408 |
