Schneider Electric MA4D-8030
SKU: CS420100MPN: MA4D-8030UPC/EAN: 711426700053
Act (MA4D-8030): Elec, 2Pos, SR, 120 VAC, App, 30 in-lb, Rotary, N2, SmartX
$334.89
Unit4 Units Available at Factory - Ships Same/Next Business Day
Product Details
Actuator: (MA4D-8030):
- Actuator Type: Electric
- Control Signal: 2-Position (On/Off)
- Loss of Power Type: Spring Return
- Power Input Voltage: 120 VAC
- Leads and Connections: 3 ft Appliance
- Torque: 30 in-lb
- Mechanical Movement: Rotary
- Protection Rating: NEMA 2
- Product Line: Schneider Electric
- Product Range: SmartX Actuator
- Product Series: MA4D-8xxx
- Actuator Use: Ball Valves, Dampers
Attributes
| Us Rated Supply Voltage | 120 V AC |
| Actuator | rotary |
| Actuator Rotation | 93 ° |
| Ambient Air Temperature For Operation | -30-60 °C |
| Ambient Air Temperature For Storage | -40-71 °C |
| Control Type | automatic reset |
| Electrical Insulation Class | class I |
| Ip Degree Of Protection | IP11 |
| Material | polymer: housing |
| Motor Type | brush DC motor |
| Power Consumption In Va | 7.8 VA AC |
| Product Destination | ball valves dampers |
| Product Or Component Type | actuator |
| Relative Humidity | 15-95 % non-condensing |
| Switch Function | No |
| Targeted Region | North America. |
| Taxoclass Id | PTC_D54013_XXX |
| Tightening Torque | 30 lb.in# #3.4 N.m |
Specifications
| SKU | CS420100 |
|---|---|
| MPN | MA4D-8030 |
| UPC/EAN | 711426700053 |
