ifm Efector PQ0834

Compound Digital Pressure Switch, (2) SPST, -14.5 psi Vac to 145 psi

Digital Pressure Sensor, Power Required 18 to 32V DC, Range -14.5 psi Vac to 145 psi, Compatible With Air, Circuit Type NPN, Output Current 100 mA, Contact Form SPST, On Set Point -13 to 145 psi, Off Set Point -14 to 144 psi, Burst Pressure 435 psi, Process Connection G⅛, IP Rating IP65, Housing Material FKM, PBT, Polyester, Wetted Materials Brass, FKM, PBT, Silicon, Electrical Connection 4 Pin M8 Connector, Temp. Range 13 Degrees to 176 Degrees F
