ifm Efector IM0054

Rctngulr Proxmity Sensr, Indctv, 3 Wire

Rectangular Proximity Sensor, Inductive, Proximity Sensor Power Requirement 24 to 240V AC/DC, Shielded, Proximity Sensor Operating Frequency 25 HZ AC/140 Hz DC, Proximity Sensor Output Circuit Type 3 Wire, Max. Detecting Distance 20 mm, Proximity Sensor Electrical Connection 3 Pin ½-20 UNF Male Connector, Output Mode NO, NEMA Rating 6, IP Rating 67, Case Material PPE, PPS, Length 66 mm, Width 40 mm, Depth 40 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 350/100mA
