Dwyer ZV1044
SKU: CS4122664MPN: ZV1044Alternate Part #: 124520-61
ZV1044 2-WAY VLV 1” 24VAC
$171.83
UnitAvailable on backorder
Product Details
Two-way zone valve, 1” NPT, 24 VAC.
Attributes
| Body | 2-way, normally closed. |
| Commodity Code | R3UA |
| Cycle Time | Opening time: 11 seconds; Closing time: 5 seconds. |
| Electrical Connection | 22 AWG, 5” (127 mm) long. |
| Enclosure Rating | General purpose. |
| End Connections | Female NPT (optional BSP, sweat connections). |
| Flow Characteristic | Quick opening. |
| Housing Material | Aluminum. |
| Input | On/off. |
| Line Size | ½” to 1”. |
| Power Consumption | 6.5 W. |
| Power Requirement | 120 VAC or 24 VAC, ±10%, 50/60 Hz, (optional 220 VAC). |
| Pressure Limit | Maximum: 300 psi (20.7 bar); Close-off: ½” to ¾”: 22 psi (1.5 bar), 1”: 14.5 psi (1 bar). |
| Service | Compatible fluids. |
| Wetted Material | Brass, stainless steel, NBR. |
Specifications
| SKU | CS4122664 |
|---|---|
| MPN | ZV1044 |
| Alternate Part # | 124520-61 |
