Dwyer UV-B112
SKU: CS4121713MPN: UV-B112Alternate Part #: 116524-00
UV-B112 28 SCFM/780 LPM AIR FM
$430.77
UnitAvailable on backorder
Product Details
Polysulfone flowmeter, range 2.5-28 SCFM (70-780 LPM) air.
Attributes
| Accuracy | ±2% FS @ 70°F ±2°F (21.1°C) and 14.7 psia (in line connection rating only). |
| Commodity Code | 5903 |
| Fitting Torque | Maximum 22 ft lb. |
| Pressure Limit | 150 psi (10.34 bar). |
| Process Connection | 1” female NPT. Optional 90° polysulfone elbow - 1” male NPT. |
| Repeatability | ±1% FS @ 70 ±2°F (21.1°C) and 14.7 psia (in line connection rating only). |
| Service | Compatible liquids or gases. |
| Wetted Material | Polysulfone body and fittings, fluoroelastomer O-rings and virgin PTFE float. |
Specifications
| SKU | CS4121713 |
|---|---|
| MPN | UV-B112 |
| Alternate Part # | 116524-00 |
