Dwyer SSV-S5F1

Name: Dwyer SSV-S5F1
Brand: Dwyer
SKU: CS4121092
Price: 351.37 USD
Availability: OutOfStock

SKU: CS4121092MPN: SSV-S5F1Alternate Part #: 124585-52

SSV-S5F1 SS VL ¾” 110VAC,NPT

$351.37

Unit

Available on backorder

Quantity

remove

add

Product Details

2-way 316SS solenoid valve, ¾”, 0.5-8 bar, fkm seal, 110 VAC

Agency Approval	CE.
Agency Approvals	CE.
Commodity Code	RVMC
Electrical Connection	DIN connection.
Enclosure Rating	NEMA 13 (IP54).
End Connections	Female NPT.
Line Size	⅛ to 2” NPT.
Mounting Orientation	Any position, best if solenoid vertically above valve.
Operating Pressure	⅛ to ¼”: 0 psi (0 bar) to 87 psi (6 bar); ⅜ to 2”: 7.3 psi (0.5 bar) to 116 psi (8 bar).
Other Material	Nylon.
Other Materials	Nylon.
Power Consumption	See table on catalog page.
Power Requirement	Standard: 110 VAC; Optional: 220 VAC; 24 VDC consult factory. See Series SRC Solenoid Coils.
Pressure Limit	174 psi (12 bar).
Service	Compatible gases and liquids.
Temperature Limits	Process: 248°F (120°C); Ambient: 32 to 149°F (0 to 65°C).
Type Of Operation	NO.
Wetted Material	Body: 316 SS; Spring: 304 SS; Seal: Fluoroelastomer.
