Dwyer RSM-2-A

Name: Dwyer RSM-2-A
Brand: Dwyer
SKU: CS4120487
Price: 2566.19 USD
Availability: OutOfStock

SKU: CS4120487MPN: RSM-2-AAlternate Part #: 124659-01

RSM-2-A ROOM STATUS MONITOR

$2,566.19

Unit

Available on backorder

Quantity

remove

add

Product Details

Room status monitor, range ±0.1” w.c., excitation 24 VAC.

Accuracy	±0.5% FS.
Commodity Code	R1BA
Communication	BACnet MSTP ASC optional.
Communications	BACnet MSTP ASC optional.
Compliance	CE, CSA (RSM only).
Dimensions	8” H x 5.4” W x 1.8” D (20.3 H x 13.7 W x 4.1 D cm).
Electrical Connection	Removable terminal block.
Enclosure Rating	NEMA 1 (IP20) rated for indoor applications.
Housing	Fire retardant plastic.
Humidity Limit	5 to 95% relative humidity (non-condensing).
Humidity Limits	5 to 95% relative humidity (non-condensing).
Loop Resistance 4 20 Ma Output	0-510 Î©.
Mounting	Mount to standard double gang metal electrical box using 4x4” plaster ring adapter.
Output Signal	Selectable 4-20 mA (2-wire), 0-5 VDC (3-wire), or 0-10 VDC (3-wire).
Power Consumption Voltage Output	5 W.
Pressure Limit	±15 in w.c. (±3.7 kPa).
Process Connection	Barbed fittings for 3/16” ID tubing.
Process Connections	Barbed fittings for 3/16” ID tubing.
Service	Air or nonconductive, nonexplosive gases.
Supply Voltage	Order Code A (24 VAC): 18-32 VAC, 50-60 Hz. Order Code B (120 VAC): 85-265 VAC, 50-60 Hz. Main supply voltage fluctuations up to 10%.
Switch Type	SPST.
Thermal Effect	±0.03% FS/ °F (± 0.05% FS/ °C).
Thermal Effects	±0.03% FS/ °F (± 0.05% FS/ °C).
