Dwyer F7-LL

Name: Dwyer F7-LL
Brand: Dwyer
SKU: CS4118169
Price: 181.62 USD
Availability: OutOfStock

SKU: CS4118169MPN: F7-LLAlternate Part #: 124252-00

F7-LL LVL SW

$181.62

Unit

Available on backorder

Quantity

remove

add

Product Details

Vertical level switch, polysulfone float, Buna-N stem, temperature limit 180°F (82°C), pressure limit 50 psig (3 bar), electrical rating 20 VA: 0.08A @ 240 VAC, 22 AWG 72” (182 cm) wire leads, ⅛” male NPT mounting, weight 2 oz (58 g).

Attributes

Agency Approval	CE.
Commodity Code	R2ND
Electrical Connection	22 AWG, 11.811” (300mm) long.
Electrical Rating	20 VA: 0.17 A @ 120 VAC, 0.08 A @ 240 VAC.
Electrical Rating Maximum	F7-SB, -SS2 AC: 25 VA, 1.0A, 200 V DC: 10 W, 1.0 A, 200 V F7-PP, -BT, -HSS, -MHS AC: 25 VA, 1.0 A, 200 V DC: 10 W, 1.0 A, 200 V F7-HPS-1, -2 AC: 25 VA, 1.0 A, 200 V DC: 10 W, 1.0 A, 200 V (F7-HSS is rated explosion-proof for Class I, Groups A, B, C, D; Class II, Groups E, F, G; Class III).
Enclosure Rating	General purpose.
Magnet	Alnico (F7-SB, -PP, -BT, -HPS), ceramic (F7-SS2, -HSS, -MHS).
Mounting Connection	⅛” NPTM (all vertical mount), ½” NPTM (F7-HPS-2, F7-HSS), M16 x 2 (F7-HPS-1), ½” x 13 thread (F7-MHS).
Mounting Orientation	F6-SS: vertical ±20°, F6-MHS/HPS: horizontal with index arrow pointing up or down.
Pressure Limit	F6-SS & F6-MHS: 218 psi (15 bar). F6-HPS-11, 21, 31: 116 psi (8 bar).
Process Connection	F6-SS: ⅛” NPT, HPS-21, 31: ½” NPT, F6-MHS, F6-HPS-11: M16*2.
Service	Compatible liquids.
Specific Gravity	F6-SS: 0.65, F6-MHS: 0.85, F6-HPS-11, 21, 31: 0.6.
Switch Type	SPST Hermetically sealed reed switch, reversible for NO or NC.
Wetted Material	See model table on catalog page.
Wire Leads	22 AWG x 18” (46 cm), vertical mount models; 22 AWG x 39” (1 m), models F7-HPS-1, -2; 22 AWG x 24” (61 cm), models F7-HSS, -MHS.
