Dwyer BTT-I08-5

Name: Dwyer BTT-I08-5
Brand: Dwyer
SKU: CS4116399
Price: 94.41 USD
Availability: OutOfStock

SKU: CS4116399MPN: BTT-I08-5Alternate Part #: 100712-36

BTT-I08-5 TEMP XMTR

$94.41

Unit

Available on backorder

Quantity

remove

add

Product Details

Immersion temperature transmitter with 4 to 20 mA output, 0 to 100 C temperature range, 8” probe

Accuracy	±0.5°C @ 25°C.
Agency Approval	CE.
Commodity Code	0731
Conduit Connection	½” NPT.
Electrical Connection	Removable terminal block, knocks out for conduit fitting.
Enclosure Rating	NEMA 4X (IP66) (immersions models require thermowell).
Output Signal	4 to 20 mA or 0 to 10 VDC (depending on model).
Power Requirement	13 to 36 VDC for current models, 13 to 36 VDC or 16 to 28 VAC for voltage models.
Process Connection	½” NPT (immersion models only).
Range	-40 to 140°F (-40 to 60°C).
Response Time	100 ms.
Temperature Sensor	Pt1000 RTD.
Thermal Effect	±0.01%/°C.
Wetted Material	All models: 304 SS (probe), polycarbonate (housing); Duct and immersion models: Neoprene (gasket); Outside air models: Nylon (insert), silicone (O-ring).
