Turck WKB 3T-5/S628
SKU: CS3887417MPN: WKB 3T-5/S628Alternate Part #: U-58605
U-58605 - CORD,½IN.MICROFAST
$31.64
UnitAvailable on backorder
Product Details
Actuator and Sensor Cordset
Connection Cordset
- Right angle Female ½″ microfast Connector
- Sheath material: PVC
- Sheath color: gray
- Resistant to chemicals and oils
- Resistant to acids and alkaline solutions
- LABS free
- RoHS-compliant
- Protection class IP67
- Cable length: 5.0 m
Attributes
| Application | Signal |
| Approvals | CSA C22.2 No. 182.3, CE, RoHS, UL Listed, UL 2238 |
| Cable Diameter | Ø 5.3 mm |
| Cable Jacket | PVC, Gray |
| Connector A | Female, ½″-20 UNF, Right angle |
| Connector Body | Plastic, TPU |
| Coupling Nut | Brass, CuZn, Nickel-plated |
| Current | 4 A |
| Customs Tariff Number | 85444290900.0000 |
| Design | Single-ended |
| Ecl Ss Code V5 1 4 | 27250107 -/- Connection cable sensor-actuator |
| Number Of Conductors | 3.0000 |
| Number Of Contacts | 3 |
| Protection Class When Coupled | IP67, IP69K |
| Special Feature | Tray cable |
| Voltage | 250 V |
Specifications
| SKU | CS3887417 |
|---|---|
| MPN | WKB 3T-5/S628 |
| Alternate Part # | U-58605 |
