Turck TPS-206A-CF-H1141-L100
SKU: CS3877977MPN: TPS-206A-CF-H1141-L100Alternate Part #: 9910638UPC/EAN: 4047101271096
9910638 - PT100, PROBE, GEN., GEN.
$176.54
UnitAvailable on backorder
Product Details
Temperature Detection
Probe, Stainless Steel
- Pt‐100 probe acc. to DIN EN 60751
- Vibration an shock-resistant
- Class A for temperatures \< 350 °C
- Class B for temperatures > 350 °C
- Can be connected to TS, TTM, IM34, BL20, BL67 and excom
- Max. temperature connector: 120°C
- Connection mode: 4-wire connection
- Process connection via compression fitting or thermowell.
Attributes
| Ambient Temperature | -40…+120 °C |
| Customs Tariff Number | 90251900900.0000 |
| Design | Temperature probe |
| Detection Type | medium contact |
| Ecl Ss Code V5 1 4 | 27200208 -/- Temperature measurement electrical complete |
| Electrical Connection | Connector, M12 × 1 |
| Electrical Output | Resistance |
| Housing Material | Stainless steel, 1.4404 (AISI 316L) |
| Measuring Range | -50…500 °C |
| Process Connection | For compression fittings, thermowell or direct mounting |
| Protection Class | IP67 |
Specifications
| SKU | CS3877977 |
|---|---|
| MPN | TPS-206A-CF-H1141-L100 |
| Alternate Part # | 9910638 |
| UPC/EAN | 4047101271096 |
