Turck PT5000PSIG-2003-I2-H1144

SKU: CS3831798MPN: PT5000PSIG-2003-I2-H1144Alternate Part #: 100002145UPC/EAN: 4047101459296

100002145 - METAL (REL) , TRANSM, GEN.,

Turck PT10000PSIG-2003-I2-H1143, PT10000PSIG-2003-IX-H1143, PT1000PSIG-2003-I2-H1141, PT1000PSIG-2003-I2-H1143, PT1000PSIG-2003-IX-H1143, PT1000PSIG-2003-U1-H1141, PT1000R-2003-IOL-H1141, PT100PSIG-2003-I2-H1141, PT100PSIG-2003-I2-H1143, PT100PSIG-2003-I2-H1144, PT100PSIG-2003-IX-H1143, PT100PSIG-2003-U1-H1141, PT100R-2003-IOL-H1141, PT100R-2003-IX-H1143, PT10R-2003-I2-H1143
$243.49
Unit
Available on backorder
remove
add

Product Details

Pressure Transmitter

With Current Output (2-Wire)

  • Fully welded metal measuring cell
  • Pressure range 0…5000 psi rel.
  • 7…33 VDC
  • Analog output 4…20 mA
  • Process connection ¼”-18 NPT male thread
  • Plug-in device, M12 × 1

Attributes

Ambient Temperature -30…+85 °C
Approvals CE, Metrological certification (RUS), cULus
Current Output 4…20 mA
Customs Tariff Number 90262020000.0000
Design Without display
Ecl Ss Code V5 1 4 27200614 -/- Piezoresistive sensor (absolute and relative pressure)
Electrical Connection Connector, M12 × 1
Electrical Output Current output (2-wire)
Housing Material Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Medium Temperature -40…+135 °C
Operating Voltage 7…33 VDC
Pressure Range Bar 0…344.74 bar
Pressure Range Psi 0…5000 psi
Pressure Transducer Material Stainless steel 1.4435 (AISI 316L)
Pressure Type Relative pressure
Process Connection ¼″ NPT-18 male thread
Protection Class IP67

Specifications

SKUCS3831798
MPNPT5000PSIG-2003-I2-H1144
Alternate Part #100002145
UPC/EAN4047101459296
