Turck PT400R-13-LI3-H1131

SKU: CS3831749MPN: PT400R-13-LI3-H1131Alternate Part #: 6831510UPC/EAN: 4047101213300

6831510 - CER (REL) , TRANSM, GEN., GEN.

Turck PT-30HG-13-LI3-H1131, PT-30HG-13-LU2-H1131, PT0.5R-13-LI3-H1131, PT001R-13-LI3-H1131, PT002R-13-LI3-H1131, PT003R-13-LI3-H1131, PT003R-13-LU2-H1131, PT004R-13-LU2-H1131, PT006R-13-LU2-H1131, PT010R-13-LI3-H1131, PT010R-13-LU2-H1131, PT016R-13-LI3-H1131, PT016R-13-LU2-H1131, PT01VR-13-LI3-H1131, PT01VR-13-LU2-H1131
$413.74
Unit
Available on backorder
remove
add

Product Details

Pressure Transmitter

With Current Output (2-Wire)

  • Compact and robust design
  • Pressure connection with integrated peak pressure aperture
  • Accuracy hardly affected by temperature within entire range ‐40…+125°C
  • Excellent EMC properties
  • Pressure range 0…400 bar rel.

Attributes

Ambient Temperature -40…+85 °C
Current Output 4…20 mA
Customs Tariff Number 90262020000.0000
Design Without display
Ecl Ss Code V5 1 4 27200614 -/- Piezoresistive sensor (absolute and relative pressure)
Electrical Connection Connector, M12 × 1
Electrical Output Current output (2-wire)
Housing Material Stainless-steel/Plastic, 1.4305 (AISI 303)
Medium Temperature -40…+125 °C
Operating Voltage 8…33 VDC
Pressure Range Bar 0…400 bar
Pressure Range Psi 0…5801.51 psi
Pressure Transducer Material Ceramic Al₂O₃
Pressure Type Relative pressure
Process Connection ¼″ NPT-18 male thread
Protection Class IP67

Specifications

SKUCS3831749
MPNPT400R-13-LI3-H1131
Alternate Part #6831510
UPC/EAN4047101213300
