Turck NI20U-S30-AP6X-0.2-RSV4T
SKU: CS3814091MPN: NI20U-S30-AP6X-0.2-RSV4TAlternate Part #: 1646590
1646590 - UPROX, BARREL, DC, PIGTAIL M12
$181.60
UnitAvailable on backorder
Product Details
Inductive Sensor
- M30 × 1.5 threaded barrel
- Plastic, PA12‐GF30
- Factor 1 for all metals
- Protection class IP68
- Resistant to magnetic fields
- Extended temperature range
- High switching frequency
- Auto-compensation protects against pre-damping
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- Pigtail with male end M12 x 1
Attributes
| Ambient Temperature | -30…+85 °C |
| Construction Size | M30 x 1.5 |
| Design | Threaded barrel |
| Ecl Ss Code V5 1 4 | 27270101 -/- Inductive proximity switch |
| Electrical Connection | Cable with connector, M12 × 1 |
| Housing Material | Plastic, PA12-GF30 |
| Mounting | Non-flush |
| Operating Voltage | 10…30 VDC |
| Output Function | NO contact, PNP |
| Protection Class | IP68 |
| Rated Switching Distance | 20 mm |
| Special Feature | uprox+, Factor 1, Resistant to magnetic fields |
| Switching Frequency | 1.0 kHz |
Specifications
| SKU | CS3814091 |
|---|---|
| MPN | NI20U-S30-AP6X-0.2-RSV4T |
| Alternate Part # | 1646590 |
