All ProductsTurck

Turck LUS211-130-51-LI2UPN8-H1141

SKU: CS3812090MPN: LUS211-130-51-LI2UPN8-H1141Alternate Part #: 100003169UPC/EAN: 4047101476255

100003169 - NO DESC

Turck LUS211-130-51-2UPN8-H1141, LUS211-130-51-LI2UPN8-H1141, LUS211-40-51-2UPN8-H1141, LUS211-40-51-LI2UPN8-H1141
Turck LUS211-130-34-2UPN8-H1141, LUS211-130-34-LI2UPN8-H1141, LUS211-130-51-2UPN8-H1141, LUS211-130-51-LI2UPN8-H1141, LUS211-40-34-2UPN8-H1141, LUS211-40-34-LI2UPN8-H1141, LUS211-40-51-2UPN8-H1141, LUS211-40-51-LI2UPN8-H1141
Turck LUS211-130-51-2UPN8-H1141, LUS211-130-51-LI2UPN8-H1141, LUS211-40-51-2UPN8-H1141, LUS211-40-51-LI2UPN8-H1141
Turck LUS211-130-34-2UPN8-H1141, LUS211-130-34-LI2UPN8-H1141, LUS211-130-51-2UPN8-H1141, LUS211-130-51-LI2UPN8-H1141, LUS211-40-34-2UPN8-H1141, LUS211-40-34-LI2UPN8-H1141, LUS211-40-51-2UPN8-H1141, LUS211-40-51-LI2UPN8-H1141
$1,084.49
Unit
Available on backorder
remove
add

Product Details

Ultrasonic Sensor

Level Control

  • 4-digit, 2-colored, 12-segment display, rotatable by 180°
  • Housing is rotatable after mounting the process connection
  • G¾” process connection
  • Sealing ring included in delivery (stainless steel ring with NBR seal)
  • Blind zone: 13 cm
  • Range: 130 cm
  • Resolution: 1 mm
  • Aperture angle of sonic cone: ±16 °
  • 1 × switching output, PNP/NPN
  • 1 × analog output, 4…20 mA / 0…10 V / additional switching output, PNP/NPN
  • NO/NC programmable
  • Transmission of process value and parametrization via IO-link

Attributes

Ambient Temperature -25…+70 °C
Approvals CE, cULus
Communication Protocol IO-Link
Current Output 4…20 mA
Customs Tariff Number 85365019900.0000
Detection Type contactless
Ecl Ss Code V5 1 4 27272803 -/- Ultrasonic proximity switch
Electrical Connection Connector, M12 × 1
Housing Material Stainless-steel/Plastic, 1.4404 (AISI 316L)/Grilamid TR90 UV PA
Max Range 1300  mm
Measuring Principle Ultrasonic
Medium liquids, Bulk goods
Operating Voltage 18…33 VDC
Output Function NO/NC, PNP/NPN, analog output
Pressure Resistance 0.5…5 bar
Process Connection G ¾’‘
Protection Class IP67/IP69K
Voltage Output 0…10 V

Specifications

SKUCS3812090
MPNLUS211-130-51-LI2UPN8-H1141
Alternate Part #100003169
UPC/EAN4047101476255
